1970-81 2nd Gen F-Body Camaro / Firebird Lightweight Chromoly Steering Column 15-260
Motion Raceworks
15-260-1
Motion Raceworks - 15-260-1
$561.00
Racing Use Only, Not Legal for Road Use
1970-81 2nd Gen F-Body Camaro / Firebird Lightweight Chromoly Steering Column 15-260
Note: This comes standard with the Motion Raceworks Quick Release Steering Hub. Pictures show Strange version, however, will be updated soon!
This bolt-in light weight chromoly steering column for a 1970-81 2nd Gen Camaro / Firebird is just the answer for saving a considerable amount of weight on your Fbody Camaro or Firebird. Simply unbolt your column, and bolt this piece back in.
This column has been tested and works great whether you are using a factory or aftermarket race seat.
Uses factory mounts AND hardware for installation. This column comes fully tig welded, and is powdercoated gloss black. Included in Kit-Outer Column-3/4" Inner shaft-Retaining collar-(2) bushings. (Note: Uses factory nuts/bolts for mounting.)
This column comes standard with a Motion Raceworks 5/6 bolt pattern SFI approved quick release installed and welded.
Steering Box Connections:
Factory Steering Box -- Comes with 30 Spline U-joint to Double D Shaft (length of Double D Shaft may require trimming to fit), and Upper U-joint 3/4" Round to 3/4 DD.
To Connect to an aftermarket Flaming River / Pinto style rack you will need the following items.
https://www.motionraceworks.com/products/steering-u-joint-9-16-26-spline-to-3-4-dd
https://www.motionraceworks.com/products/steering-u-joint-3-4-smooth-to-3-4-dd
https://www.motionraceworks.com/products/3-4dd-steering-shaft?variant=17816995856502
Learn about U-joints and and Intermediate Steering Shafts by watching this video!
